Traffic Flow Analytics Camera

>All-in-one camera(EXCEPT LENS)
>Adopt 1/1.9inch Starlight CMOS image sensor, high color reducibility, high sensitivity, super Low-Light effect
>Adopt H.264 standard HD video format and 25fps HD video frame rate
>Embedded integration component design, built-in a variety of algorithms, such as traffic data collection and analysis, vehicle type classification and so on
>Up to 80m of traffic data counting range
>The accurate of detection is over 99%, when the speed is below 80km/h
>A variety of signals, data and communication interface
Technical Data
Image Sensor 1/1.9inch CMOS(8.58mm)
Max. Resolution 2.3 Megara, 1920×1200
Lenses Support P-Iris
Camera Speed Shutter 1/25 ~ 1/100000
Day/Night Auto ICR (with polarized lens and infrared filter)
Video Signal Interface 1 ×CVBS port and 2 ×100/1000M Ethernet port
Digital I/O 2 Relay output – 1 optical coupling input – 8 optical coupling input
Extra Interface 2 ×Mini USB and 1 ×SD interface
Power AC 90~285V ,<25W
Dimensions 540mm×174.2mm×143mm
Ingress Protection IP66
Working Environment Temperature -40°C~+80°C, Humidity 10%~90%
Software Features
Traffic Data Counting Performance: Up to 4 line for traffic data counting

Vehicle type: Passenger Car, Large Truck, Mid Truck, Saloon Car, Micro bus, Micro Truck

Statistical data of each lane: time, date, statistical period, lane, Traffic flow, occupancy, headway, average speed, queue length, vehicle type of each line

Monitor Lane 1~4 lanes
Video Compression H.264H, H.264M, H.264B, MJEPG
Remote control function Configure through WEB client
OSD information superimposed Support, Information of the video include time and place (channel address), Lane information (number)
Image Records Tamper-resistance Video/Image with watermark tech and check function
CE SECE1606281
FCC SEFD1606281
