DHL550UCH-ES

55’’ FHD Video Wall Display Unit (Ultra Narrow Bezel 3.5mm)

> Industrial level DID LCD panel, suitable for extensive 24/7 continuous works
> Ultra-narrow 3.5mm bezel-to bezel design(2.3mm bezel on the left and top sides and 1.2mm bezel on the right and bottom sides)
> High contrast and high brightness greatly enhance the video layering, and present the details of the video
> High fidelity digital processing, brilliant and vivid video
> Built-in 3D COMB filter and 3D Noise Reduction
> Abundant interfaces HDMI, DVI, VGA, BNC, support video loop
> Built-in picture splicing function
> Infrared, RS232 double mode, supporting remote PC control
> Fan smart detection, OSD prompt
> Brightness smart detection, power-saving
> Professional thermal design to extend equipment lifespan
> Built-in power, low energy consumption, ultra-quiet
> Fast stack installation, professional project design, supporting arc-shaped mounting
> Widely used in MCC(monitor command center), Dispatching Platform, Safe City

Download
Model
Model DHL550UCH-ES
System
Diagonal 55″(16:9)
LCD Technology PVA
Resolution 1920×1080 (FHD)
Bezel width 2.3mm(U/L), 1.2mm(R/B)
Backlight Direct LED
Brightness/Luminance (Standard) 700 cd/
Contrast 4000:1
Pixel Density 40dpi
Viewing Angle H178°, V178°
Response time 8ms
Display Color 8bit(16.7M)
Color Temperature 10,000K
MTBF 50,000h
Video Signals
Video Input CVBS(BNC)×2
PC Signal VGA(D-Sub)×1
Digital Signal DVI-D×1 [1080P(1920×1080), downward compatible]
HDMI×1 [1080P(1920×1080), downward compatible]
Loop Out CVBS(BNC)×2
General
Consumption (Standard) 150W
Consumption (Standby) ≤1W
Power Supply AC90~264V (+/-5%), 50/60 Hz
Installation Mode (all optional) Modular Stacking/ Cabinet installation (Back up)
Control Signal Infrared, RS232 double mode, supporting remote PC control
Gross Weight 38.5kg
Net Weight 31.5kg
Dimension(no structure) 1213.6×684.4×116.1mm
Work Environment Temperature: 0~+50
Humidity: 10%~90%
