ARC5402A-GW

Video Alarm Control Panel

> 2 wired zones, 1 alarm out
> 32 wireless zones, bi-directional communication, transimission range up to 150m open space
> 8 wireless remote control (ARA22-W)
> 4 wireless sirens + 1 wired siren
> 4CH@D1 IPC
> Arm and disarm by ID card
> 1 ch audio in for 30s voice message
> 1 ch audio out for voice and alarm broadcast
> TCP/IP, GSM(-G only), PSTN
> Max 128GB SD card for video recording
> 4.3 inch TFT screen, 480*272 resolution
> Main power: DC12V/2A
> Backup battery: 3.7V/1900mAh, Li-ion
> CE, FCC, MABISZ

Download
System
Main Processor High-performance industrial embedded microcontroller
Operating System Embedded LINUX
Power Management System Main power and backup battery automatic transfer, main power failure alarm, battery power indicator, low battery alarm
In and Out
Wired Zones 2 on-board zones
Wireless Zones 32 wireless zones, bi-directional communication, transmission range up to 150m open space
Alarm Output 1-ch relay output
Tamper Funtion 1 tamper switch
Remote Control 8 wireless remote controls
Siren 4 wireless sirens + 1 wired siren
Storage Max 128GB micro SD card for video recording, USB device to backup video
ID Card RFID reader(arm/disarm)
Network
Network Function TCP/IP, DHCP, WIFI, P2P, GSM(-G only), IP Search(Support Dahua IP camera), DMSS
Interface
Network Interface 1 RJ-45 Port(10/100Mbps)
RS485 1 Port
PSTN 2 groups PSTN, support Contact ID standard protocol alarm
Wired Siren 1 wired siren(12V/0.5A)
Auxiliary Power Output 1 auxiliary power output(12V/0.5A)
Reset Insert two ends of cable into the holes to reset
USB 1 USB 2.0 port to record or upgrade
Audio and Video
IP Camera Channel 4 Channel
Compression H.264
Resolution D1
LCD Screen 4.3 inch TFT screen, 480*272 resolution
Audio In 1 ch audio in for 30s voice message
Audio Out 1 ch audio out for voice and alarm broadcast
Upgrade
Remote Upgrade USB disk or ConfigTool to remotely upgrade
General Parameters
Main Power DC12V/2A
Backup Battery 3.7V/1900mAh, Li-ion
Power Consumption ≤5W
Operating Temperature -10℃ ~ +55℃
Humidity 10% ~ 90%
Device Dimensions 216*118*28 (L*W*H) mm
Device Weight 1kg
Installation Wall mounting
Certifications
Certifications CE, FCC, MABISZ
