ASR1200D ASR1200D-D

Slim Water-proof RFID Reader

> Support RS485, Wiegand34 protocol(Wiegand 26 optional)
> 13.56MHz(Mifare)
> 125KHz(EM-ID)
> Red and Blue LEDs
> Watch dog function ensure device free from halting
> Water-proof(Outdoor use)
> Surface/Flush mounted installation
Download
Categories: ,
Technical Specification
Model ASR1200D ASR1200D-D
System
Main Processor 8 Bit
Read
Read Format 13.56MHz 125KHz
Read Range 6-8cm (max.)
Reading time <0.1s
Function
Tamper Alarm Yes
Interface
To Controller RS485, Wiegand34(Wiegand 26 optional)
General
LED Indicator Yes
Ingress Protection IP65
Beep Tone Buzzer
Power Supply 5-16V DC / 100mA/ 300mA/ 800mA
Working Environment -30°C-+60°C
Working Humidity ≤95%
Dimension(W×D×H) 135*47.5*16mm
Weight 0.18kg
