TPC-BF2120-T

Thermal Network Mini Hybrid Bullet Camera

> 160×120 VOx uncooled thermal sensor technology
> Athermalized Lens (thermal camera), Focus-free
> 1/2.8” 2Megapixel progressive scan Sony cmos
> Support ROI, Motion Detection, Color Palettes
> Support temperature measurement
> Support Fire detection & alarm
> Built-in 2/1 alarm in/out
> Micro SD memory, IP67, PoE

Download
Thermal Camera
Image Sensor Uncooled VOx Microbolometer
Effective Pixels 160(H)x120(V)
Pixel Size 12um
Thermal Sensitivity (NETD) <50mK@f/1.1
Spectral Range 7~14um
Image Setting Brightness/Sharpness/ROI/AGC/FFC/3D DNR
Color Palettes 14(Whitehot/Blackhot/Ironrow/Icefire/

Fusion/Rainbow/Globow/Iconbow1/

Iconbow2 .etc)

Thermal Lens
Lens Type Fixed
Focus Control Athermalized, Focus-free
Focal Length 1mm
Effective Distance①

Man(1.8m*0.5m)

D②: 60m

R③: 20m

I ④: 10m

Effective Distance

Vehicle(2.3m*2.3m)

D: 200m

R: 60m

I: 30m

Angle of View H: 56°

V: 44°

Visible Camera
Image Sensor 1/2.8″ 2M CMOS
Effective Pixels 1944(H)x1092(V)
Electronic Shutter Speed 1/1 ~ 1/30,000s
Min. Illumination Color: 0.005Lux@F1.8; B/W: 0.0005Lux@F1.8; 0Lux (IR on)
IR Distance 35m
IR On/Off Control Auto/Manual
IR LEDs 1
Visible Lens
Focal Length 4mm
Max Aperture F2.0
Angle of View H: 86.2°

V: 45.9°

Temperature Measurement
Measurement Range -20°C ~+450°C
Measurement Accuracy Low temperature -20°C ~+150°CMax (±5°C, ±5%);

High temperature +150°C ~+450°CMax ±8%;

Measurement Mode Spot/Line/Area
Measurement Rule Spot: 12

Line: 12

Area12

Support 12 rules simulaneously

Video
Compression H.264/MJPEG
Frame Rate Main Stream:

Thermal: 1280*960 (default)/720P@1~25/30fps

Visible: 1080P (default)/720P@1~25/30fps

Sub Stream:

Thermal: 640*480 (default)/ 320*240@1~25/30fps

Visible: CIF(default)/D1@1~25/30fps

Bit Rate Control CBR/VBR
Bit Rate H.264: 640 ~ 8192Kbps
Day/Night Auto(ICR)/Color/B/W
BLC Mode BLC/HLC/WDR
White Balance Auto, Manual
Noise Reduction Ultral DNR
Motion Detetion Off/On (4 zone, Rectangle)
Region of Interest Off/On (4 zone)
Electronic Image Stabilization

(EIS)

NA
Defog Off/On
Flip 180°
Mirror Off/On
Privacy Masking Off/On (4 area, Rectangle)
Audio
Compression G.711a/G.711Mu/AAC
Intelligence
IVS Tripwire, Intrusion, Object Abandon/Missing
Advanced Intelligent Functions Fire detection & alarm, Temperature measurement
Network
Ethernet RJ-45 (10/100Base-T)
Protocol IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour, 802.1x
Interoperability ONVIF Profile S & G, PSIA, CGI
Streaming Method Unicast/Multicast
Max. User Access 10 Users/20 Users
Edge Storage micro SD (128GB) Memory status display (Normal/Error/Active/ Formatting/Lock),

NAS (Network Attached Storage), Local PC for instant recording

Web Viewer
Management Software Smart PSS, DSS
Smart Phone Android, IOS
Certifications
Certification CE (EN 60950:2000) FCC (FCC Part 15 SubpartB )
Interface
Video Interface 1.0Vp-p/75Ω, PAL/NTSC (HDCVI Optional)
Audio Interface In/Out 1/1
RS485 Support
Alarm 2/1 In/Out
Electrical
Power Supply DC 12V/PoE
Power Consumption 12W (IR on), 9W(IR off)
Environmental
Operating Condition -30°C ~ +55°C (-22°F ~ +131°F)/Less than 95% RH

* Start up should be done at above -30°C (-22°F)

Strorage Conditions -40°C ~ +70°C (-40°F ~ +158°F)/Less than 95% RH
Ingress Protection IP67
Construction
Casing Metal
Dimensions 238.6mm × 90.4mm× 90.4mm (9.39″ x 3.56″ x 3.56″)

(With bracket)

Weight < 1Kg
