4U 24HDD AI Network Video Recorder

> Intel quad-core processor
> Max 512Mbps incoming bandwidth
> 256 Channel IP video access
> Up to 32 Channel video stream face recognition
> Up to 80 Channel picture stream face recognition
> Regular/stranger mode
> Search by image
> Face database management
> Supports RAID 0/1/5/6/10
> SAS3.0 for storage extension
> 3HDMI/1VGA video output
> Redundant power


Main Processor Intel Quad-core Processor
Memory 16GB, up to 64GB
Operating System Embedded LINUX
Artificial Intelligence
Face Recognition 32 channel video stream face recognition / 80 channel picture stream face recognition (with FD camera)
Performance 80 face pictrues /sec processing (modeling and comparing)
Metadata Sturctured data of gender, age, expression, glasses, moustache, mouth mask information.
Stranger Mode Detect strangers’ faces(not in device’s face database).Similarity threshold can be set manually.
Trigger Events Buzzer, snapshot, recording, etc.
Search by Image Up to 10 target face images search at same time. Support similarity threshold set for each target face image.
Database Management Up to 20 face databases with 100,000 face images in total. Name, gender, birthday, nationality, address, ID information can be added to each face picture.
Database Application Each database can be applied to video channels independently.
Audio and Video
IP Camera Input 256 Channel
Two-way Talk 1 × 3.5mm audio input, 1 × 3.5mm audio output
Interface 3 HDMI, 1VGA
Resolution HDMI1/2/3 : 3840 × 2160 , 1920 × 1080 , 1280 × 1024,

1280 × 720

VGA : 1920 × 1080 , 1280 × 1024,

1280 × 720

Decoding Capability 24-ch@1080P(30fps)
Multi-screen Display Up to 36 split for each screen
OSD Camera title, Time, Motion detection, Recording
Bandwidth 450Mbps
Compression H.265/H.264/MJPEG/MPEG4
Resolution 12MP, 8MP, 6MP, 5MP, 4MP, 3MP, 1080P, etc.
Record Mode Schedule (Continuous, Event)
Video Detection and Alarm
Trigger Events Recording, Snapshot, Buzzer, etc.
Video Detection Motion Detection, MD Zones: 396 (22 × 18); Tampering
Alarm input 16 Channel
Relay Output 8 Channel
Playback and Backup
Sync Playback Up to 16ch sync playback, 128Mbps playback bandwidth
Search Mode Time /Date, Video Detection, Face and Exact Search (accurate to second)
Backup Mode USB Device/Network
Third-party Support
Third-party Support AXIS, Panasonic, Sony, etc.
Interface 4 RJ-45 Ports (10/100/1000Mbps)
Optional Interface 4 Giga Optical Fiber Interface
Network Port Mode Independent Ethernet Ports, Load Balance, Fault-Tolerance, Link Aggregation
Network Function HTTP, HTTPS, TCP/IP, UDP, RTSP, IPv4, NTP, DHCP, DNS, IP Filter, IP Search (Support Dahua IP camera, DVR, etc.), P2P
Interoperability ONVIF 2.4, SDK
Internal HDD 24 SAS/SATA HDDs, Up to 10 TB capacity for each HDD, Independent HDD bracket, hot-swap
HDD Mode Single, Raid 0/1/5/6/10(Enterprise-level HDDs are recommended), Support Global HDD Hot-spare
eSATA 1 eSATA Port (Please contact technical engineer to confirm the compatible device)
SAS 2 SAS3.0 Ports
Auxiliary Interface
Front Cover Support Hot-swap7-inch HD LCD (1920 × 1080 , 1280 × 1024)
USB 4 USB Ports (2 USB 2.0 , 2 USB 3.0 )
RS232 1 Port, for PC Communication
RS485 1 Port
Power Supply AC100V ~ 240V, 50 ~ 60 Hz, Hot-swap, Redundant
Power Consumption <130W (Without HDD)
Fan Dual-ball bearing fans, Hot-swap
Operating Conditions 0°C ~ +45°C (+32°F ~ +113°F), 86 ~ 106kpa
Storage Conditions -20°C ~ +70°C (-4°F ~ +158°F), 0 ~ 90% RH
Dimensions 4U, 482.6mm x 543.4mm x 175mm (19″ x 21.39″ x 6.89″)
Net Weight 20kg (44.09 lb) (without HDD)
Installation Standard 19-inch Rack-mounted
CE EN55032, EN55024, EN50130-4, EN60950-1
FCC Part 15 Subpart B, ANSI C63.4-2014
UL UL 60950-1
