IVSS7008-1T

2U 8HDD AI Network Video Recorder

> Intel dual-core processor
> Max 400Mbps incoming bandwidth
> 128 Channel IP video access
> Up to 4 Channel video stream face recognition
> Up to 10 Channel picture stream face recognition
> Regular/stranger mode
> Search by image
> Face database management
> Supports RAID 0/1/5/6/10
> 3HDMI/2VGA video output

Download
System
Main Processor Intel Dual-core Processor
Memory 8GB, up to 32GB
Operating System Embedded LINUX
Artificial Intelligence
Face Recognition 4 channel video stream face recognition / 10 channel picture stream face recognition ( with FD camera)
Performance 10 face pictures /sec processing (modeling and comparing)
Metadata Sturctured data of gender, age, expression, glasses, moustache, mouth mask information.
Stranger Mode Detect strangers’ faces(not in device’s face database).Similarity threshold can be set manually.
Trigger Events Buzzer, snapshot, recording, etc.
Search by Image Up to 10 target face images search at same time. Support similarity threshold set for each target face image.
Database Management Up to 20 face databases with 100,000 face images in total. Name, gender, birthday, nationality, address, ID information can be added to each face picture.
Database Application Each database can be applied to video channels independently.
Audio and Video
IP Camera Input 128 Channel
Two-way Talk 1 audio input, 2 audio output, RCA
Display
Interface 3 HDMI, 2VGA
Resolution HDMI1/2/3 : 3840 × 2160 , 1920 × 1080 , 1280 × 1024,

1280 × 720

VGA1/2 : 1920 × 1080 , 1280 × 1024,

1280 × 720

Decoding Capability 20-ch@1080P(30fps)
Multi-screen Display Up to 36 split for each screen
OSD Camera title, Time, Motion detection, Recording
Recording
Bandwidth 320Mbps
Compression H.265/H.264/MJPEG/MPEG4
Resolution 12MP, 8MP, 6MP, 5MP, 4MP, 3MP, 1080P, etc.
Record Mode Schedule (Continuous, Event)
Video Detection and Alarm
Trigger Events Recording, Snapshot, Buzzer, etc.
Video Detection Motion Detection, MD Zones: 396 (22 × 18); Tampering
Alarm input 16 Channel
Relay Output 8 Channel
Playback and Backup
Sync Playback Up to 16ch sync playback, 64Mbps playback bandwidth
Search Mode Time /Date, Video Detection, Face and Exact Search (accurate to second)
Backup Mode USB Device/Network
Third-party Support
Third-party Support AXIS, Panasonic, Sony, etc.
Network
Interface 4 RJ-45 Ports (10/100/1000Mbps)
Network Port Mode Independent Ethernet Ports, Load Balance, Fault-Tolerance, Link Aggregation
Network Function HTTP, HTTPS, TCP/IP, UDP, RTSP, IPv4, NTP, DHCP, DNS, IP Filter, IP Search (Support Dahua IP camera, DVR, etc.), P2P
Interoperability ONVIF 2.4, SDK
Storage
Internal HDD 8 SATA HDDs, Up to 10 TB capacity for each HDD
HDD Mode Single, Raid 0/1/5/6/10(Enterprise-level HDDs are recommended), Support Global HDD Hot-spare
eSATA 1 eSATA Port (Please contact technical engineer to confirm the compatible device)
Auxiliary Interface
USB 4 USB Ports (2 USB 2.0 , 2 USB 3.0 )
RS232 1 Port, for PC Communication
RS485 1 Port
Electrical
Power Supply AC100V ~ 240V, 50 ~ 60 Hz
Power Consumption <120W (With HDD)
Environmental
Operating Conditions 0°C ~ +45°C (+32°F ~ +113°F), 86 ~ 106kpa
Storage Conditions -20°C ~ +70°C (-4°F ~ +158°F), 0 ~ 90% RH
Construction
Dimensions 2U, 439.7mm x 446.2mm x 90.8mm (17.32″ x 17.57″ x 3.57″)
Net Weight 8.55kg (18.85lb) (without HDD)
Installation Standard 19-inch Rack-mounted
Certifications
CE EN55032, EN55035, EN50130-4, EN60950-1
FCC Part 15 Subpart B, ANSI C63.4-2014
UL UL 60950-1
